How to Design a Production-Grade CAMEL Multi-Agent System with Planning, Tool Use, Self-Consistency, and Critique-Driven Refinement

import os, sys, re, json, subprocess
from typing import List, Dict, Any, Optional, Tuple

def _pip_install(pkgs: List[str]):
subprocess.check_call([sys.executable, “-m”, “pip”, “install”, “-q”, “-U”] + pkgs)

_pip_install([“camel-ai[web_tools]~=0.2”, “pydantic>=2.7”, “rich>=13.7”])

from pydantic import BaseModel, Field
from rich.console import Console
from rich.panel import Panel
from rich.table import Table

console = Console()

def _get_colab_secret(name: str) -> Optional[str]:
try:
from google.colab import userdata
v = userdata.get(name)
return v if v else None
except Exception:
return None

def ensure_openai_key():
if os.getenv(“OPENAI_API_KEY”):
return
v = _get_colab_secret(“OPENAI_API_KEY”)
if v:
os.environ[“OPENAI_API_KEY”] = v
return
try:
from getpass import getpass
k = getpass(“Enter OPENAI_API_KEY (input hidden): “).strip()
if k:
os.environ[“OPENAI_API_KEY”] = k
except Exception:
pass

ensure_openai_key()
if not os.getenv(“OPENAI_API_KEY”):
raise RuntimeError(“OPENAI_API_KEY is not set. Add it via Colab Secrets (OPENAI_API_KEY) or paste it when prompted.”)

from camel.models import ModelFactory
from camel.types import ModelPlatformType, ModelType
from camel.agents import ChatAgent
from camel.toolkits import SearchToolkit

def make_model(temperature: float = 0.2):
return ModelFactory.create(
model_platform=ModelPlatformType.OPENAI,
model_type=ModelType.GPT_4O,
model_config_dict={“temperature”: float(temperature)},
)

def strip_code_fences(s: str) -> str:
s = s.strip()
s = re.sub(r”^(?:json)?\s*”, “”, s, flags=re.IGNORECASE)
s = re.sub(r”\s*$”, “”, s)
return s.strip()

def extract_first_json_object(s: str) -> str:
s2 = strip_code_fences(s)
start = None
stack = []
for i, ch in enumerate(s2):
if ch == “{“:
if start is None:
start = i
stack.append(“{“)
elif ch == “}”:
if stack:
stack.pop()
if not stack and start is not None:
return s2[start:i+1]
m = re.search(r”\{[\s\S]*\}”, s2)
if m:
return m.group(0)
return s2

class PlanTask(BaseModel):
id: str = Field(…, min_length=1)
title: str = Field(…, min_length=1)
objective: str = Field(…, min_length=1)
deliverable: str = Field(…, min_length=1)
tool_hints: List[str] = Field(default_factory=list)
risks: List[str] = Field(default_factory=list)

class Plan(BaseModel):
goal: str
assumptions: List[str] = Field(default_factory=list)
tasks: List[PlanTask]
success_criteria: List[str] = Field(default_factory=list)

class EvidenceItem(BaseModel):
query: str
notes: str
key_points: List[str] = Field(default_factory=list)

class Critique(BaseModel):
score_0_to_10: float = Field(…, ge=0, le=10)
strengths: List[str] = Field(default_factory=list)
issues: List[str] = Field(default_factory=list)
fix_plan: List[str] = Field(default_factory=list)

class RunConfig(BaseModel):
goal: str
max_tasks: int = 5
max_searches_per_task: int = 2
max_revision_rounds: int = 1
self_consistency_samples: int = 2

DEFAULT_GOAL = “Create a concise, evidence-backed technical brief explaining CAMEL (the multi-agent framework), its core abstractions, and a practical recipe to build a tool-using multi-agent pipeline (planner/researcher/writer/critic) with safeguards.”

cfg = RunConfig(goal=DEFAULT_GOAL)

search_tool = SearchToolkit().search_duckduckgo

planner_system = (
“You are a senior agent architect. Produce a compact, high-leverage plan for achieving the goal.\n”
“Return ONLY valid JSON that matches this schema:\n”
“{{\”goal\”: \”…\”, \”assumptions\”: [\”…\”], \”tasks\”: ”
“[{{\”id\”: \”T1\”, \”title\”: \”…\”, \”objective\”: \”…\”, \”deliverable\”: \”…\”, ”
“\”tool_hints\”: [\”…\”], \”risks\”: [\”…\”]}}], ”
“\”success_criteria\”: [\”…\”]}}\n”
“Constraints: tasks length <= {max_tasks}. Each task should be executable with web search + reasoning.”
).format(max_tasks=cfg.max_tasks)

planner = ChatAgent(system_message=planner_system, model=make_model(0.1))

researcher = ChatAgent(
system_message=(
“You are a meticulous research agent. Use the web search tool when useful.\n”
“You must:\n”
“- Search for authoritative sources (docs, official repos) first.\n”
“- Write notes that are directly relevant to the task objective.\n”
“- Return ONLY valid JSON:\n”
“{\”query\”: \”…\”, \”notes\”: \”…\”, \”key_points\”: [\”…\”]}\n”
“Do not include markdown code fences.”
),
model=make_model(0.2),
tools=[search_tool],
)

writer = ChatAgent(
system_message=(
“You are a technical writer agent. You will be given a goal, a plan, and evidence notes.\n”
“Write a deliverable that is clear, actionable, and concise.\n”
“Include:\n”
“- A crisp overview\n”
“- Key abstractions and how they connect\n”
“- A practical implementation recipe\n”
“- Minimal caveats/limitations\n”
“Do NOT fabricate citations. If evidence is thin, state uncertainty.\n”
“Return plain text only.”
),
model=make_model(0.3),
)

critic = ChatAgent(
system_message=(
“You are a strict reviewer. Evaluate the draft against the goal, correctness, and completeness.\n”
“Return ONLY valid JSON:\n”
“{\”score_0_to_10\”: 0.0, \”strengths\”: [\”…\”], \”issues\”: [\”…\”], \”fix_plan\”: [\”…\”]}\n”
“Do not include markdown code fences.”
),
model=make_model(0.0),
)

rewriter = ChatAgent(
system_message=(
“You are a revising editor. Improve the draft based on critique. Preserve factual accuracy.\n”
“Return the improved draft as plain text only.”
),
model=make_model(0.25),
)

def plan_goal(goal: str) -> Plan:
resp = planner.step(“GOAL:\n” + goal + “\n\nReturn JSON plan now.”)
raw = resp.msgs[0].content if hasattr(resp, “msgs”) else resp.msg.content
js = extract_first_json_object(raw)
try:
return Plan.model_validate_json(js)
except Exception:
return Plan.model_validate(json.loads(js))

def research_task(task: PlanTask, goal: str, k: int) -> EvidenceItem:
prompt = (
“GOAL:\n” + goal + “\n\nTASK:\n” + task.model_dump_json(indent=2) + “\n\n”
f”Perform research. Use at most {k} web searches. First search official documentation or GitHub if relevant.”
)
resp = researcher.step(prompt)
raw = resp.msgs[0].content if hasattr(resp, “msgs”) else resp.msg.content
js = extract_first_json_object(raw)
try:
return EvidenceItem.model_validate_json(js)
except Exception:
return EvidenceItem.model_validate(json.loads(js))

def draft_with_self_consistency(goal: str, plan: Plan, evidence: List[Tuple[PlanTask, EvidenceItem]], n: int) -> str:
packed_evidence = []
for t, ev in evidence:
packed_evidence.append({
“task_id”: t.id,
“task_title”: t.title,
“objective”: t.objective,
“notes”: ev.notes,
“key_points”: ev.key_points
})
payload = {
“goal”: goal,
“assumptions”: plan.assumptions,
“tasks”: [t.model_dump() for t in plan.tasks],
“evidence”: packed_evidence,
“success_criteria”: plan.success_criteria,
}
drafts = []
for _ in range(max(1, n)):
resp = writer.step(“INPUT:\n” + json.dumps(payload, ensure_ascii=False, indent=2))
txt = resp.msgs[0].content if hasattr(resp, “msgs”) else resp.msg.content
drafts.append(txt.strip())
if len(drafts) == 1:
return drafts[0]
chooser = ChatAgent(
system_message=(
“You are a selector agent. Choose the best draft among candidates for correctness, clarity, and actionability.\n”
“Return ONLY the winning draft text, unchanged.”
),
model=make_model(0.0),
)
resp = chooser.step(“GOAL:\n” + goal + “\n\nCANDIDATES:\n” + “\n\n—\n\n”.join([f”[DRAFT {i+1}]\n{d}” for i, d in enumerate(drafts)]))
return (resp.msgs[0].content if hasattr(resp, “msgs”) else resp.msg.content).strip()

def critique_text(goal: str, draft: str) -> Critique:
resp = critic.step(“GOAL:\n” + goal + “\n\nDRAFT:\n” + draft + “\n\nReturn critique JSON now.”)
raw = resp.msgs[0].content if hasattr(resp, “msgs”) else resp.msg.content
js = extract_first_json_object(raw)
try:
return Critique.model_validate_json(js)
except Exception:
return Critique.model_validate(json.loads(js))

def revise(goal: str, draft: str, critique: Critique) -> str:
resp = rewriter.step(
“GOAL:\n” + goal +
“\n\nCRITIQUE:\n” + critique.model_dump_json(indent=2) +
“\n\nDRAFT:\n” + draft +
“\n\nRewrite now.”
)
return (resp.msgs[0].content if hasattr(resp, “msgs”) else resp.msg.content).strip()

def pretty_plan(plan: Plan):
tab = Table(title=”Agent Plan”, show_lines=True)
tab.add_column(“ID”, style=”bold”)
tab.add_column(“Title”)
tab.add_column(“Objective”)
tab.add_column(“Deliverable”)
for t in plan.tasks:
tab.add_row(t.id, t.title, t.objective, t.deliverable)
console.print(tab)

def run(cfg: RunConfig):
console.print(Panel.fit(“CAMEL Advanced Agentic Tutorial Runner”, style=”bold”))
plan = plan_goal(cfg.goal)
pretty_plan(plan)

evidence = []
for task in plan.tasks[: cfg.max_tasks]:
ev = research_task(task, cfg.goal, cfg.max_searches_per_task)
evidence.append((task, ev))

console.print(Panel.fit(“Drafting (self-consistency)”, style=”bold”))
draft = draft_with_self_consistency(cfg.goal, plan, evidence, cfg.self_consistency_samples)

for r in range(cfg.max_revision_rounds + 1):
crit = critique_text(cfg.goal, draft)
console.print(Panel.fit(f”Critique round {r+1} — score {crit.score_0_to_10:.1f}/10″, style=”bold”))
if crit.strengths:
console.print(Panel(“Strengths:\n- ” + “\n- “.join(crit.strengths), title=”Strengths”))
if crit.issues:
console.print(Panel(“Issues:\n- ” + “\n- “.join(crit.issues), title=”Issues”))
if crit.fix_plan:
console.print(Panel(“Fix plan:\n- ” + “\n- “.join(crit.fix_plan), title=”Fix plan”))
if crit.score_0_to_10 >= 8.5 or r >= cfg.max_revision_rounds:
break
draft = revise(cfg.goal, draft, crit)

console.print(Panel.fit(“FINAL DELIVERABLE”, style=”bold green”))
console.print(draft)

run(cfg)
